Birch Plywood For Laser Cutting

Plywood is perfectly made for being cut and engraved with a laser system ,but Not all plywood can be used for laser cutting.

INQUIRY

CONTACT

Product Details

Plywood is perfectly made for being cut and engraved with a laser system ,but Not all plywood can be used for laser cutting.

Product Description:

Product name	High Quality 25mm 17 ply B/BB BB/CP 100% FSC White Birch Plywood
Face and Back	1.5mm or 0.3mm birch veneer B/BB,S/BB.BB/BB/BB/CP,CP/C
Core	1.5mm birch veneer
Thickness	4mm,6mm,6.5mm,8mm,9mm,10mm,12mm,15mm,18mm,21mm,24mm,25mm,30mm
Size	1220x2440mm,1250x2500mm
Glue	Phenolic wbp, E0,E1
Grade	B/BB BB/CP CP/CP
Moisture	5%-14%
Package	Standard export packing
Press	One times press/two time press grade
Thickness Tolerance	≤6mm: ±0.2mm to ±0.3mm 6mm-38mm: ±0.4mm to ±0.5mm
Usages	Usage adequate for making furniture or construction, package or industry
Certification	CE, ISO9001, FSC, CARB etc.

Specifications

Quality Control:

We have 15 QC teams to inspection such as moisture control, glue inspection both before production and after production, material grade selection, pressing checking, and thickness checking.

Grade as following:

Face/back veneer 1.2~1.5mm(Finland Baltic Standard) B--S--BB--CP--C
B ( Ⅰ)GradeThe Highest Grade,Unfilled,sanded veneer in which no plugs are allowed,no splices, no patchesFew small open knots and hair cracks,small mineral streaks may exist,Natural discolouring is marginally allowed.
S ( Ⅰ)GradeThe "S" Grade is a middle grade between "B"and "BB" Gradeinclude 0-3 colour-selected wooden plugs on S-side.Plugs show are batwing shapes
BB(Ⅲ) Grade unfilled and sanded veneer to which repairs by means of plugs are allowed.3-6 small color-matched patches on average and some light mineral streaksTight pin knots may be present.along with small, closed splits. Color variations are allowedPlugs show are batwing shapes
CP((Ⅲ/WG+) GradeThe "CP" Grade are downgraded from ”BB“ ; grade veneers, which allow for unlimited patches and sound knots, Open splits and checks up to 4mm wide. Discolouration, streaks, roughness, glue penetration and plugs permitted
C (Ⅳ/WG)GradeIn addition to all before mentioned flaws, this grade of veneer may include larger deficienciesPatches, open knots, and small veneer splits allowed. Veneer lap and small core voids permitted.
